P-47D Thunderbolt V2 from Dynam

Details

This is the improved version (V2) of the popular Dynam P-47D Thunderbolt. This new version now includes a Tomcat Skylord 40 Amp ESC with XT60 connector, pre-installed flaps, pre-installed flap servos, LED lights with pre-soldered connector ends and LED light controller for static and flashing operations.  The Republic P-47 Thunderbolt is one of the largest and heaviest fighter aircraft in history to be powered by a single piston engine.  It was built from 1941-1945.  It was heavily armed with eight .50-caliber machine guns, four per wing.  When fully loaded, the P-47 weighed up to eight tons, and in the fighter-bomber ground-attack roles could carry five-inch rockets or a significant bomb load of 2,500 pounds; it could carry more than half the payload of the B-17 bomber on long-range missions.  Dynam brings the P-47D Thunderbolt back to life with this exciting new 1220mm (48") wingspan - PNP version.  All you need is a 5 channel radio, 5 channel receiver and 4S 14.8V 2500-3000 mAh Li-Po battery with XT60 connector to take to the skies!

Features:

  • Tomcat Skylord 40 Amp ESC with XT60 connector
  • Flaps and flap servos are now pre-installed and fully operational
  • LED navigation lighting with LED control board (no more bare leads)
  • Model officially licensed by Northrop Grumman
  • Realistic scale features including Hun Hunter XVI paint scheme, hand painted pilot figure, gun turrets, and molded panel lines
  • Servoless electronic retractable landing gear
  • Powerful BM3720A-KV500 Brushless Outrunner motor
  • Scale 3-blade propeller

Descriptions and Pictures from Motion RC

Pictures

Manual

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.


Wingspan: 1220mm (48 in)
Length: 1050mm (41.3 in)

Weight: 1500 g (3.3 lbs)
Wingspan 1220mm / 48in
Length 1050mm /41in
Flying Weight 1500g / 53oz
CG (Center of Gravity) 70 - 75mm from the leading edge at the wing root
Power System BM3720A-KV500 Brushless Outrunner Motor
Electronic Speed Control 40A Brushless with XT60 connector
Propeller / EDF 3-Blade Prop
Servos 4x 9g standard
Landing Gear Electronic retractable main gear
Required Battery 4S 14.8V 2500mAh or 3000mAh LiPo with XT60 connector (required)
