Model R from Eclipson Airplanes

Details

Eclipson model R is an airplane designed with one main objective: Achieve the maximum speed possible using our standard power pack. Thin laminar airfoil, narrow and streamlined fuselage are some of the key factors that explain why this plane reaches 100+ MPH (170KM/H) with our recommended standard power pack. The airframe is extremely strong, reinforced with carbon fiber tubes you won't have to worry about pulling extreme G-maneuvers while flying fast.

One of the main advantages of our designs is that you can choose the wing loading that you want depending on your piloting level and/or preferences. The PLA version with a wing loading of 59g/dm2 is just perfect to fly fast, that is in fact the typical wing loading that you will find on pylon racers. But if your level is not so high and you just want to enjoy a nice sport plane the LW-PLA version is the best option, with a wing loading of 42 g/dm2 the plane will be able to cruise at a much lower speed making this model great also for intermediate pilots

STL available on Eclipson Website

Pictures

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Model R in particular but at least we know they do distribute Eclipson Airplanes.

Where to buy


Wingspan: 1030mm (40.6 in)
Length: 780mm (30.7 in)

Weight: 640 g (1.4 lbs)
  • Wingspan: 1,030 mm
  • Wing Surface: 15.2 dm²
  • Wing Aspect Ratio: 6.9
  • Wing Airfoil: MH24
  • Length: 780mm
   LW-PLA  PLA
Structure Weight 220g  450g
Take Off Weight 640g 900g
Stall Speed 27km/h 34km/h
Wing Loading 42g/dm² 59/gr/dm²
