A-10 Thunderbolt II from fms

Details

he Fairchild Republic A-10 Thunderbolt II is a single–seat, twin turbofan engine, straight wing jet aircraft developed by Fairchild-Republic for the United StatesAir Force (USAF).
Commonly referred to by its nicknames Warthog or Hog, its official name comes from the Republic P-47 Thunderbolt, a World War II fighter that was effective at attacking ground targets.

FMS is proud to bring to you this new and highly detailed Twin ducted fan version of the A-10. Incorporating many of the new and advanced construction and assembly features such as the optimized screw based assembly, ball links and a heavy duty wing spar and latest multi-connect technology. The “Hog” will assembly quickly. In addition the A-10 uses our newest locked-rotor mode E-retract system coupled with our refined and oriented CNC-processed metal landing gear set for resisting those not-too-perfect landings. The power system utilizes our new and improved twin 70mm 12-blade EDF V2, KV1850 inner-running motor system provides tremendous power and speed when couple with a 6S battery.

This highly detailed A-10 has to be seen to fully appreciate the detail FMS has undertaken. From all-around rivets and panel lines, detachable bomb and missile sets and pilot figure, the A-10 is an absolute must have for any pilot.

Features:

  • Powerful twin inner running motors with the latest 70mm 12-blade EDF, plus the high-quality Predator 70A ESC
  • Super highscale detail throughout:
  • Scaled CNC-processed metal landing gear set
  • Detachable bomb and missile set
  • Pilot figure
  • Panel lines and rivets…
  • The latest high-brightness LED set
  • Thelatest locked-rotor mode E-retract with overcurrent protection
  • Multi-connector for one-step installation
  • Metal digital servos for excellent controlling capacity
  • Bearings in wheel hub for better performance
  • Button Type canopy hatch
  • Large battery compartment
  • Pre-installed, newly designed ball link style control horns for more throw.

Pictures

Manual

Fairchild Republic A-10 Thunderbolt II


Fairchild Republic A-10 Thunderbolt II

The Fairchild Republic A-10 Thunderbolt II is a single-seat, twin-turbofan, straight-wing, subsonic attack aircraft developed by Fairchild Republic for the United States Air Force (USAF). In service since 1977, it is named after the Republic P-47 Thunderbolt, but is commonly referred to as the "Warthog" or simply "Hog". The A-10 was designed to provide close air support (CAS) to ground troops by attacking enemy armored vehicles, tanks, and other ground forces; it is the only production-built aircraft designed solely for CAS to have served with the U.S. Air Force. Its secondary mission is to direct other aircraft in attacks on ground targets, a role called forward air controller-airborne; aircraft used primarily in this role are designated OA-10.

The A-10 was intended to improve on the performance and firepower of the Douglas A-1 Skyraider. The Thunderbolt II's airframe was designed around the high-power 30 mm GAU-8 Avenger rotary autocannon. The airframe was designed for durability, with measures such as 1,200 pounds (540 kg) of titanium armor to protect the cockpit and aircraft systems, enabling it to absorb damage and continue flying. Its ability to take off and land from relatively short and/or unpaved runways permits operation from airstrips close to the front lines, and its simple design enables maintenance with minimal facilities.

It served in the Gulf War (Operation Desert Storm), the American-led intervention against Iraq's invasion of Kuwait, where the aircraft distinguished itself. The A-10 also participated in other conflicts such as the Balkans, Afghanistan, the Iraq War, and against the Islamic State in the Middle East.

The A-10A single-seat variant was the only version produced, though one pre-production airframe was modified into the YA-10B twin-seat prototype to test an all-weather night-capable version. In 2005, a program was started to upgrade the remaining A-10A aircraft to the A-10C configuration, with modern avionics for use with precision weaponry. The U.S. Air Force had stated the Lockheed Martin F-35 Lightning II would replace the A-10 as it entered service, but this remains highly contentious within the USAF and in political circles. The USAF gained congressional permission to start retiring A-10s in 2023, but further retirements were paused until the USAF can demonstrate that the A-10's close-air-support capabilities can be replaced.



This article is an extract from the Wikipedia article "Fairchild Republic A-10 Thunderbolt II", which is released under the Creative Commons Attribution-Share-Alike License 3.0

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the A-10 Thunderbolt II in particular but at least we know they do distribute fms.

Where to buy

France
Flash RC
check web site
Ship to: Europe
Switzerland
Grischa Modellbau
check web site
Ship to: Switzerland
Germany
Voltmaster
check web site
Ship to: Europe
USA
TOWER HOBBIES
check web site
Ship to: International
USA
Flite Test Store
check web site
Ship to: Worldwire
Ireland
Model Heli Service
check web site
Ship to: Ireland
United Kingdom
Model Shop Leeds
check web site
Ship to: United Kingdom
France
Breizh Modelisme
check web site
Ship to: Europe
USA
Hobby Zone
check web site
Ship to: USA
Belgium
Aerobertics
check web site
Ship to: Europe
Australia
Austars Model
check web site
Ship to: Worldwide
Switzerland
Wieser Modellbau
check web site
Ship to: Switzerland
France
miniplanes
check web site
Ship to: France
Usa
Horizon Hobby USA
check web site
Ship to: USA
France
Turbines RC
check web site
Ship to: Worldwide
Austria
DMT
check web site
Ship to: Europe
USA
Graves RC
check web site
Ship to: USA
USA
Atlanta Hobby
check web site
Ship to: USA
Belgium
Beez2B
check web site
Ship to: Europe
France
Absolu Modélisme
check web site
Ship to: France
Australia
Daves Toys for Big Boys
check web site
Ship to: Australia
Germany
Modellbau Berlinski
check web site
Ship to: International
United Kingdom
tjd Models
check web site
Ship to: United Kingdom
France
interModel
check web site
Ship to: France
United Kingdom
Arrow Models
check web site
Ship to: Europe
Netherlands
RC webshop
check web site
Ship to: Europe
USA
AMain Hobbies
check web site
Ship to: USA
France
Breizh Modelisme
check web site
Ship to: Europe
United Kingdom
Als Hobbies
check web site
Ship to: United Kingdom
China
Fair RC
check web site
Ship to: USA and Canada

Wingspan: 1500mm (59.1 in)
Length: 1368mm (53.9 in)

Weight: 4100 g (9 lbs)

Wingspan: 1500mm
Overall Length: 1368mm
Flying Weight: Around 4100g
Motor Size: Inner running Brushless 2860 KV1850 x 2
ESC: 70A x 2
Servo: 17g metal digital Servo x 4, 9g metal digital Servo x 5
Radio: 6 Channel (aileron, elevator, rudder, flaps, retracts)
CG: 80-85mm (From Leading Edge)
Recommended Battery: Li-Po 22.2V 5000mAh 45C
Approx. Flying Duration: 4 min
Assembly Time: 30 minutes
Material: Durable EPO
