Voltigeur MkII from HobbyKing

Details

The Voltigeur is a well-known performer and we've just taken it to the next level. Flying the Voltigeur is a dream, using the recommended 3S Lipo battery for aerobatics and sports flying it handles like a trainer, docile and extremely predictable, But it morphs into a 3D beast with that very same 3s battery. Everything from rolling circles, waterfalls, inverted harriers and blenders, nothing will stop the Voltigeur.

We have improved the motor design to provide more power (1900g thrust), better efficiency and cooler running (5% lower temp). To help with the extremes of 3D flying the servo arms have been beefed up and the landing gear has been improved with carbon fiber legs. No more applying stickers as they are factory fitted too. There is even a bigger, better ESC access hole for more airflow.

The Voltigeur is a true aerobatic performer and extreme 3D flying machine. Construction is from lightweight EPO foam and features large control surfaces coupled with masses of power. Perfectly balanced with a mid-mounted full symmetrical wing, large battery compartment, composite glass fiber wing tube, metal gear high-speed servos all round and all electronics pre-installed. Orientation is not a problem with the highly visible and unique color scheme.

Features:
• EPO foam lightweight construction
• Large control surfaces for extreme 3D flying
• New powerful motor package for 1900g of thrust on 3S 11.1V (34A), 13x6.5, 9% increase
• High-speed metal gear servos
• Ball link control horns
• Better servo horns to handle all the 3D stress
• Large easy to access battery hatch
• Composite glass fiber wing tube
• Carbon Fiber undercarriage with lightweight wheels
• High strength nylon wing bolts
• Highly visible and unique combination decals (factory fitted)
• Scale pilot figure

Pictures

Manual

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Voltigeur MkII in particular but at least we know they do distribute HobbyKing.

Wingspan: 1220mm (48 in)
Length: 1280mm (50.4 in)

Weight: 1500 g (3.3 lbs)

Wingspan: 1220mm (48")
Length: 1280mm (50")
Take off Weight: 1500g (approx)
Motor: 4028 1000KV Brushless outrunner
ESC: 45A w/ 3A BEC
Prop: 12x8

Requires:
1 x Minimum 4-6 channel transmitter and receiver
1 x 3S Lipo battery 2200~2600mAh 45-65c
1 x Licence to thrill
