ECHO5 from OddityRC

Radio-Controlled Multirotor for RC Pilots

Details

Features:

Designed by OddityRC team
Supports the DJI O4P and video transmitters with a maximum length of 36 mm or less
Built with T700 carbon fiber and a 7075 aluminum front mount, the ECHO5 delivers exceptional rigidity, lightweight performance, and reliable lens protection.
Can mount Insta360, Gopro, Action2 and other sports camera
Suitable for outdoor freestyle flying and cinematic shooting.

Pictures

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the ECHO5 in particular but at least we know they do distribute OddityRC.

Where to buy

Wingspan: 225mm (8.9 in)
	Length: 225mm (8.9 in)
Weight: 200 g (7.1 oz)

See more Details

Specification	ECHO 5 X	ECHO 5 DC
Product Name	ECHO 5 X	ECHO 5 DC
Wheelbase	225 mm (8.86 in)	230.9 mm (9.09 in)
Propeller Size	124.5–129.5 mm (4.9–5.1 in)	124.5–129.5 mm (4.9–5.1 in)
Weight	199 g (7.02 oz)	203 g (7.16 oz)
Top Plate Thickness	2.5 mm (0.10 in)	2.5 mm (0.10 in)
Middle Plate Thickness	2.5 mm (0.10 in)	2.5 mm (0.10 in)
Arm Thickness	5.5 mm (0.22 in)	5.5 mm (0.22 in)
Bottom Plate Thickness	2.5 mm (0.10 in)	2.5 mm (0.10 in)
FC Mounting Hole Spacing	20 × 30.5 mm (0.79 × 1.20 in), M3	20 × 30.5 mm (0.79 × 1.20 in), M3
VTX Mounting Hole Spacing	20 × 25.5 mm (0.79 × 1.00 in)	20 × 25.5 mm (0.79 × 1.00 in)
Motor Mounting Hole Spacing	16 mm (0.63 in)	16 mm (0.63 in)
Camera Mounting Hole Spacing	19–20 mm (0.75–0.79 in)	19–20 mm (0.75–0.79 in)
