These files are large, so be patient during the download. Please read the readme.txt included in the ZIP
Whether you are an ambitious beginner or an advanced model pilot, the Arcus II is the right choice when looking for a powerful and compact glider with electric propulsion. Whether fast or slow, agile or calm, powered or gliding, with this model you always have the right all-rounder in action. The model is controlled via three axes. Thanks to its powerful drive set, the Arcus II has enough power for climbing and then gliding in good thermals. Despite its wingspan of 1,840 mm, it can be easily transported thanks to the divisible wing. The model comes with four mounted servos for aileron, rudder and elevator as well as a mounted drive set. CFRP reinforcements in the fuselage and wings, as well as the undercarriage and two plastic protectors for the fuselage complete the scope of delivery. The model can be retrofitted with flaps in no time at all. The large ailerons already have an embossed dividing line for this retrofit, as well as the mounting points for the additional rudder horns. The wings are equipped with cable ducts for the additional servos. Thus only the available retrofit set as well as two further 8 - 9 g servos, a suitable adhesive and of course a free channel at the remote control/receiver are needed. Of course, the installation is described in the illustrated building instructions.
Features:
FrSky X20
FrSky XE
PNG (300x280)
BMP Recommended (300x280)
FrSky X18
FrSky Twin
PNG (180x166)
BMP Recommended (180x166)
FrSky X10
FrSky X12s
PNG (180x160)
BMP Recommended (180x160)
PNG (192x114)
FrSky X9D
FrSky X9E
BMP (64x32)
JPG (155x100)
