UH-1A Huey from RotorScale

Details

With the quality of Roban fiberglass fuselages the RotorScale 450 PNP Helicopter Series seeks to bring scale helicopter flying within the reach of pilots with basic collective pitch flight experience who are looking to move upward toward larger scale 500-800 size helicopters.

Using a 4S 1600mAh - 2200mAh battery, fly for 5-6 minutes while exploring the flight envelope of this sport scale stabilized helicopter. The durable fiberglass bodies are finished in automotive paint and clearcoat for durability, and feature sharp panel lines, rivets, and other surface details.

Digital servos provide precise and responsive action, and breakaway landing gear plates help divert damage during hard landings away from major frame components. If ever required, the internal frame can be completely removed from the body in a few minutes with eight screws. Fully backed by Motion RC’s world renowned service, a complete line of spare parts is available to keep you flying.

Features:

  • Roban quality fiberglass fuselage complete with sharp panel lines, rivets and other surface details.
  • Receiver-Ready (PNP) convenience so you can be flying in a short amount of time right out of the box.

Pictures

Manual

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the UH-1A Huey in particular but at least we know they do distribute RotorScale.

Wingspan: 750mm (29.5 in)
Length: unknown

Weight: unknown
Class / Size 450 Size
Power Type Electric
Rotor Type Collective Pitch
Body Material Fiberglass
Overall Size (L x W x H) 750 x 180 x 250mm
Flying Weight
Main Rotor Diameter 740mm
Main Rotor Blade Length 325mm
Tail Rotor Diameter 162mm
Tail Rotor Blade Length 61mm
Tail Drive Type Belt
Cyclic Servos eMax ES09MD metal gear
Tail Servo eMax ES9258 metal gear
Power System 450L-1800Kv Brushless Motor
Electronic Speed Control 40A Brushless with XT60 connector
Recommended Battery 4S 14.8V 1600-2200mAh LiPo with XT60 Connector
Required Radio 6 Channel
