Westland Lysander from Seagull Models

Details

The Westland Lysander was a British army co-operation and liaison aircraft produced by Westland Aircraft and was used immediately before and during the Second World War. The first Lysanders entered service in June 1938, equipping squadrons for army co-operation and were initially used for message-dropping and artillery spotting. British army air co-operation aircraft were named after mythical or historical military leaders; in this case the Spartan general Lysander was chosen.

The New Seagull Westland Lysander 3000mm has an accurate scale outline with superb flying characteristics. It is made of high quality balsa and plywood covered in genuine oracover film, and has a detailed cockpit with a painted pilot figure with an amazing matte finish. All necessary hardware are included for either glow or electric power system.

As a Suggestion, the engine size could be 33cc - 55cc gasoline 2 Stroke or 40 - 60cc 4-stroke. It is also ideally suited to the OS Saito 5 Cylinder Radial.

Features:

  • High quality balsa and balsa plywood, these make light weight construction.
  • Eye Catching Scale Colour Scheme.
  • Covered in Genuine Oracover Film Covering with matte finish. It makes airplane real scale.
  • Factory Painted Fibreglass Engine Cowl and wheel pants.
  • Detailled Cockpit with Light Weight Painted Pilot figure adds sporty, scale detail.
  • Allows easy access to radio components and to the flight battery for those choosing an electric Power option.
  • The aluminum landing gear reinforcement.
  • Superb flying characteristics, plus an accurate scale outline
  • Two-piece, plug-in wings simplify transportation and assembly
  • All necessary hardware included for either glow or electric power system

Pictures

Manual

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.


Wingspan: 2997mm (118 in)
Length: 1788mm (70.4 in)

Weight: 10000 g (22 lbs)
  • Wingspan: 2997mm (118 in)
  • Wing area: 94.9 dm² (1471sq.in)
  • Approximate flying weight: 10,000 g (22lbs)
  • Length: 1788 mm (70.4 in)
  • Power system:
    • Gasoline 2-stroke 33cc-55cc or
    • 4-stroke 40cc-60cc or
    • electric
  • Servos Required 8
  • CG (Centre of Gravity) 27mm infront of the leading edge of the wing
  • Assembly time (approx.) 10 - 15 hours
