Element from TOPMODEL CZ

Details

One of the most impressive European made sailplanes that we have ever seen. The brand new competition F5J/ALES Element 3.5E flies as good as it looks. Gentle, smooth, and very long flights are the standards for this beauty. The careful use of composites with competition balsa, creates a good light structure that will hold its shape for a long time. The synergy of low weight and strong structure is very unusual in a production sailplane and can only be achieved with careful attention to design and construction. The entire model is constructed using free-flight techniques. Top Model uses the latest construction techniques such as CNC milling and laser cutting. The wings as well as horizontal and vertical tail parts are all classic balsa with Carbon Fiber main spare and leading edge design. The fuselage is gel-coated fiberglass with white finish and CF canopy. Whole model is covered with Ultracote. All control surfaces are hinged with adhesive tape. This fully built sailplane needs only basic assembly and motor/radio installation. The 3-piece wing and full flying stabilizer are each easily removable for transport and storage. Each part is carefully hand-crafted with meticulous attention to detail. Value is simply incredible.

Features:

  • Lightweight gel-coated white fiberglass fuselage and canopy
  • Three-piece wing is made in balsa framework with wing joiner, leading edges and wing spar made of carbon and covered with Oracover®
  • Lightweight wings are made in a balsa framework and covered with Oracover®
  • Removeable tail surfaces are made in a balsa framework and covered with Oracover®
  • Vinyl cnc cut stickers
  • Top quality accessories
  • Complet assembly manual with step by step illustrations

Pictures

Manual

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.


Wingspan: 3500mm (137.8 in)
Length: 1800mm (70.9 in)

Weight: 2300 g (5.1 lbs)
  • Wingspan:137.75" (3500mm)
  • Length:71" (1800mm)
  • Weight:4.75-5 lbs. (2155-2300g)
  • Motor
    • Good: AXi 46/760, 15x8 folding
    • Better: Race 2014/5100 6.7:1, 16x8 folding
  • Battery: 3300 3S Lipo
  • Spinner: 40mm
  • Wing Surface: 77,5 dm²
  • Wing loading: 27,1 - 29,7 g/dm²
