Zlin 526 from VQ Model

Details

The Z-526 was originally designed by Zlin Aircraft in 1959. Its two-seat version is called the Trener-Master

The Z 526's layout was organized with the pilot in the rear, and the student in front. The aircraft could be equipped also with tip tanks and a constant speed propeller. The Z-526F was introduced in 1968 and was equipped with a 135 kW (180 hp) Avia M 137A engine, the export version Z-526L differing by being equipped with a 150 kW (200 hp) Lycoming AEIO-360 flat-four. Single-seat versions included the Z-526A, Z-526AS, and the Z-526AFS.

Now , VQ Introduce the Zlin 526 55 size EP-GP. This Zlin 526 come with 2 scale flap , 1 x painted pilot , Scale spiner and many scale detail inside cockpit will make your Zlin 526 look like a real one . .

With the big battery hatch , you can use both Electric motor or Nitro engine

As an option , the Electric retracts with scale struts are a good choise for this Zlin 526 ,It make this Zlin 526 become one of the best Balsa sacle Civilian 50 size in the market . .

Product features

  • ARF finished model in wood construction (lasercut)
  • Ready strung as shown
  • Functional landing flaps
  • Electric retractable landing gear optionally available
  • Rigid landing gear included
  • Incl. wheels, linkages, small parts
  • Detailed illustrated instructions


Pictures

Manual

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.


Wingspan: 1610mm (63.4 in)
Length: 1190mm (46.9 in)

Weight: 3200 g (7.1 lbs)
  • Wingspan: 1610mm
  • Length: 1190mm
  • Weight: 3200g

Recommended Equipments

  • Engine : 55/ 2 stroke or 72-82/ 4 stroke
  • Propeller : 13x6 – 14 x6
  • Radio : 6 channesl with 7 servos ( 1 x standard servos for elevator , 1 standard servo for rudder , 2 standard servo for aileron , and 3x Mini servo ( 19grams ) for Flap and Throtte )
  • Electric Motor : Boost 50 motor or any
  • Electric Motor same size with 55 2 stroke engine
  • Battery : Lipo 14,8V 4500-5000 mAh
