These files are large, so be patient during the download. Please read the readme.txt included in the ZIP
Extremely portable Snipe 2/2 El allows you to bring the model with you anywhere. The box dimensions for the single model is just 810x190x70 mm.
Wing fitting construction adds 5 gr. only to the model weight.
High-strength joiner and the unique wing joint design ensures the integrity of the glider at launch with full power. Autoclave molding secures high durability of the wing joiner which is made of high-tech carbon prepreg.
Snipe 2/2 El has the additional pin around which the aileron horn rotates. The pin is mounted along the aileron hinge axis. This pin eliminates the vertical movement of the aileron and prevents the flutter.
We make two-part wing Snipe 2/2 El for both right- and left-handers. Consider it before ordering.
Be sure to tape the wing joint on both sides before the flight!
FrSky X20
FrSky XE
PNG (300x280)
BMP Recommended (300x280)
FrSky X18
FrSky Twin
PNG (180x166)
BMP Recommended (180x166)
FrSky X10
FrSky X12s
PNG (180x160)
BMP Recommended (180x160)
PNG (192x114)
FrSky X9D
FrSky X9E
BMP (64x32)
JPG (155x100)
Some content in menu 2.
SNIPE2 El Light UHM
SNIPE2 El
SNIPE2 El UHM
SNIPE2 El Strong
Fuselage
SNIPE2 Fuselage Light (for right- or left-handed)
29 g (1,03 oz)
SNIPE2 Fuselage (for right- or left-handed)
32,5 g (1,14 oz)
SNIPE2 Fuselage Strong (for right- or left-handed)
36 g (1.27 oz)
Nose cone
SNIPE2 Nose Cone Light
5,9 - 6,1 g (0,18-0,21 oz )
SNIPE2 Nose Cone
7,7-8.1 g ( 0,25-0,28 oz)
Wing
SNIPE2 Wing Light UHM
92-98 g (3.25-3.46 oz)
SNIPE2 Wing
101-110 g (3.56 – 3.88 oz)
SNIPE2 Wing UHM
SNIPE2 Wing Strong
115-125 g (4.06 - 4.41 oz)
Horizontal stabilizer
SNIPE2 Stabilizer Light
SNIPE2 Stabilizer Regular
5,5-6,2 g (0.19 - 0.22 oz)
SNIPE2 Stabilizer Strong
Vertical stabilizer
SNIPE2 Fin Light
SNIPE2 Fin Regular
5,8 – 6,2 g (0.2 - 0.22 oz)
Details like screws, crevices
4.5 g (0.16 oz)
NT model weight*
216.4-226.5 gr (7.62-7.97 oz)
230.4-241.5 gr (8.11-8.5 oz)
RTF weight **
260-265 gr (9.17-9.34 oz)
281.4-291.5 gr (9.91-10.26 oz)
304.4-315.5 gr (10.72-11.11 oz)
Wing loading
14.32-14.83 grdm²
