Booby from Wowings

Details

The Booby is a RC flying wing glider designed for slope soaring. Our new 2005 design update with modified planform and new specially designed airfoil section has improved it's all-round performance significantly. It has a broader speed range and improved turning performance. It can now be slowed down a little easier for landings and lighter lift conditions but it's awesome top speed has still been maintained, if not increased!

The Booby is a very fast flyer and retains speed through turns very well. It will fly fine in around 10 knots of wind on a good slope but 15 to 20 knots is ideal. It can comfortably handle up to around 30 knots of wind without any additional ballast weight. It has been designed for intermediate to advanced flyers seeking a top performing wing that will stand out from the crowd. With it's very unusual appearance and impressive flying performance it's sure to grab everyone's attention!

Features

  • CNC cut EPP foam wing panels for incredible durability
  • 9mm (approx. 3/8") diameter fiberglass spar for in-flight rigidity
  • Wide (up to 60mm, or 2 3/8") balsa elevator and ailerons with tapered cross-section for superior integration with airfoil
  • Pre-marked coreflute for fins
  • Quality Dubro pushrods and connectors
  • Detailed construction manual with photos

Pictures

Manual

Radio icons

(Click on the icon you want to download)
Horus OpenTx
Horus FrOs
Standard
Silhouette
X9D/X9D+/X9E
FrSky X20/X20s/XE Ethos
FrSky X18/X18s Ethos

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Booby in particular but at least we know they do distribute Wowings.

Where to buy

Australia
Wowings
check web site
Ship to: Worldwide

Wingspan: 1200mm (47.2 in)
Length: unknown

Weight: 840 g (1.9 lbs)
  • Wingspan: 1200 mm. (47 inches)
  • Typical flying weight: 840 grams (29.6 ounces)
  • Typical wing loading: 30.7 g/dm^2 (10.1 oz/ft^2)

Radio requirements:

  • Transmitter and receiver (minimum 2 channel)
  • Receiver battery pack in flat configuration
  • Two (2) standard size servos (eg.BlueBird BMS-621 or Hitec HS-322)
  • One (1) mini size or metal geared micro size servo (eg. BlueBird BMS-380MG, Hitec HS-85MG)
  • One (1) 300mm (12") servo extension lead
  • One (1) “Y” lead.

Kit construction requirements :

  • 48mm (approx. 2") wide cross-weave filament tape
  • 48mm (approx. 2") wide coloured covering tape or iron-on covering (eg. UltraCote or ProFilm)
  • 3M Super 77 ("multi-purpose") spray adhesive
  • Various glues (eg. 5 minute epoxy, goop/goo, hot-melt glue)
  • Utility knife (large disposable retractable variety is ideal).
  • Sandpaper and basic tools (screwdrivers, pliers etc.)
  • 1mm (approx. 1/16") thick lead flashing for nose weight

Variants

booby
Booby (Multicolor)
