P-47 Thunderbolt from hangar 9

Details

The Hangar 9® P-47 Thunderbolt PNP bridges the gap between foam and balsa pilots perfectly! For the sport and club pilot looking to transition from a foam to balsa/wood aircraft, the new P-47 Thunderbolt delivers a true Plug-N-Play® completion Fun Scale model of one of the most popular WWII warbirds ever modeled. Foam RC pilots will be familiar with the P-47 brushless outrunner power system, wide variety of battery options and easy field assembly. It features lightweight, balsa and plywood construction with carbon fiber reinforcements and is finished in genuine UltraCote® that's long lasting and easy to maintain. The two-piece plug-in wings allows for convenient transportation and set up. Pilots can be ready to fly in much less time than it takes to charge a battery. At the workbench, the P-47 assembly is easy with only common tools needed. All you need to do is bolt the model together, install the receiver, charge a battery and fly. Flying a balsa warbird aircraft has never been easier. The new Hangar 9® P-47 Thunderbolt PNP makes it easy to fly and look good doing it.

For the sport and club pilot looking to transition from a foam to balsa aircraft, the new Hangar 9® P-47 Thunderbolt delivers a true Plug-N-Play® completion replica model of one of the most popular WWII warbirds ever modeled. Foam RC pilots will be familiar with the P-47 brushless outrunner power system, wide variety of battery options and easy field assembly, while the all-wood airframe is finished in genuine UltraCote® that's long lasting and easy to maintain.

The P-47 Thunderbolt is crafted from the ground up to be the perfect first balsa aircraft for foam pilots looking to step up into the scale world of RC warbirds. As a Plug-N-Play completion level, the P-47 Thunderbolt broadens its appeal for first time balsa pilots and balsa enthusiasts looking for a plane with high play value and low assembly time.

Features:

  • Expertly constructed with lightweight, laser-cut balsa and plywood
  • Plug-N-Play® Completion Level
  • Fits a wide variety of battery options to provide a wide range of performance and flight times.
  • Two decal sets lets you customize the trim in "Wicked Wabbit" or "Hun Hunter" livery
  • No glue required for main assembly and can be ready to fly in much less time than it takes to charge a battery (Glue is recommended for 6S LiPo battery operation)
  • Painted fiberglass cowl
  • Optional simulated radial engine included
  • 60-amp Spektrum™ Avian™ Smart ESC provides real-time battery voltage, current, motor RPM and other data via compatible receivers and transmitters
  • Factory-installed 4250-600Kv Brushless Outrunner Motor
  • Landing gear doors and pilot increase realistic appeal
  • Four factory-installed Spektrum™ A391 servos
  • Large magnetic top hatch makes access to electronics and batteries convenient.
  • Two-piece plug in wings for easier transportation and field assembly
  • Factory-installed Hangar 9® electric main retractable landing gear
  • Covered in genuine Hangar 9® UltraCote® film
  • Efficient 14 x 12 wood propeller included for 4S Lipo battery powered. (5S and 6S LiPo batteries require a propeller change)

Pictures

Manual

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the P-47 Thunderbolt in particular but at least we know they do distribute hangar 9.

Wingspan: 1435mm (56.5 in)
Length: 1092mm (43 in)

Weight: 2915 g (6.4 lbs)
Battery Sold Separately
CG (Center of Gravity) 90mm (80mm-95mm range)
Power Type Electric
Material Wood
Minimum Speed Control 60A
Motor Size 4250-600kv
Motor Type Brushless - Outrunner
Product Length 43" (1092 mm)
Product Weight 103 oz, 6.4lb, 2915g
Propeller Size 14x12
Recommended Motor Battery 4S 14.8V 5000mAh LiPo Battery
Speed 70+
Wingspan 56.5" (1435 mm)
