• Wingspan: 1550 mm (61 in)
• Length: 1524 mm (60 in)
• Power Type: Electric
• ESC: 100 A
• Battery: 6S 5000 mAh LiPo
• Radio Requirement: Minimum 5-channel radio with 4 high-torque servos

Recommended CG Range and Control Throws

• The optimal center of gravity (CG) for the 61" Raven is located " in front of the wing tube (+/- 1/2")
• Aileron Control Throws
  • Low Rates - 15 deg. (30% Exp)
  • Mid Rates - 30 deg. (40% Exp)
  • High Rates - 45 deg. (50% Exp)
• Elevator Control Throws
  • Low Rates - 15 deg. (30% Exp)
  • Mid Rates - 30 deg. (40% Exp)
  • High Rates - 45 deg. (50% Exp)
• Rudder Control Throws
  • Low Rates - 15 deg. (30% Exp)
  • Mid Rates - 30 deg. (40% Exp)
  • High Rates - Max Throw (50% Exp)
