Bonanza from Durafly

Details

The Durafly Bonanza is based on the late 1940’s civilian aircraft the Beechcraft Bonanza. With a low wing and a wingspan of only 950mm, this is a plane that you can take anywhere. Durafly has designed it as an easy hand launcher.

It is built of superbly finished, tough EPO and comes with stickers already applied. All electrics are pre-installed, just fit your receiver and battery. For better control, Durafly has fitted ball links on all control surfaces. The Bonanza is ready to "Throw it and Show it"

The Bonanza has a big wing that makes it a stable flier, but has heaps of power and will easily do the major tricks, loops and rolls, with poise. After a successful flight, you can slow down and float in for a stress-free belly landing.

Features:
• Quick, easy assembly
• Superbly finished, highly compressed EPO construction
• Hand launch, belly landing
• 4 Channels (ailerons, elevator, rudder (V-Tail), throttle)
• Ball links for control surfaces
• Strong, fully molded plastic cowl and belly skid
• Full 4 channel control: Elevator, rudder, throttle and aileron
• V-Tail tailplane
• Aileron servo covers

Pictures

Manual

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Bonanza in particular but at least we know they do distribute Durafly.

Wingspan: 950mm (37.4 in)
Length: 650mm (25.6 in)

Weight: 540 g (1.2 lbs)

Wingspan: 950mm (37.4")
Length: 650mm (25.6")
Flying Weight: 540g (19.5oz) (inc all electronics and battery)
Servo: 9g x 4
ESC: 20A
Motor: 1300KV
Propeller: 7x5
Suggested battery: 3S 1300mAh
CG position: 70mm +/- 5mm
Control surface throws: ±8mm

Suggested Set-Up:
C of G: 80mm ± 5mm (measured from leading edge at root of wing)
Elevator: 8mm each way (+ 30% exponential)
Ailerons: 8mm each way (+ 25% exponential)
Rudder: 12mm each way (+ 25% exponential)
