FW 190 D-9 Dora from FlightLine RC

Details

Motion RC and FlightLine are pleased to offer the next in their line of Pocket Warbird Series, the Fw 190 D-9 Dora.  Like the first in the series, the P-51D Mustang, the Dora can be flown on both 3S and 4S LiPo batteries. With a wide flight envelope from 3S slow and stable to high adrenaline yank and bank on 4S, the Dora will surely check off a lot of boxes for RC pilots. Simply underhand toss and boss and land on grass with confidence due to the skid-proof underside covering. Easy to transport, make the Dora one of your models you can't leave behind when headed to the flying field.

Features:

  • Compatible with both 3S and 4S LiPo batteries
  • 60+ mph with 3S LiPo battery
  • 80+ mph with 4S LiPo battery
  • Gyro-ready
  • Beginner-friendly wing loading
  • Upgrade-friendly components and layout
  • Durable structural enhancements
  • Skid-proof underside covering
  • Screw-on one-piece wing

Pictures

Manual

Radio icons

(Click on the icon you want to download)
Horus OpenTx
Horus FrOs
Standard
Silhouette
X9D/X9D+/X9E
FrSky X20/X20s Ethos

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the FW 190 D-9 Dora in particular but at least we know they do distribute FlightLine RC.

Where to buy

Netherlands
Motion RC B.V.
check web site
Ship to: Europe
USA
Motion RC LLC
check web site
Ship to: USA

Wingspan: 850mm (33.5 in)
Length: 820mm (32.3 in)

Weight: 540 g (1.2 lbs)
  • Model Scale: 1/12 Scale
  • Wingspan: 850mm / 33.5in
  • Length: 820mm /32.3in
  • Empty Weight: 540g / 19.04oz (w/o battery)
  • CG (Center of Gravity): 67mm (2.63") from the leading edge of the wing at the root
  • Power System: 3S-4S 2836-950Kv Brushless Outrunner Motor
  • Electronic Speed Control: 30A, XT60 Connector
  • Propeller / EDF: 9x6 2-Blade Propeller
  • Servos:
    • 9g plastic gear standard with 300mm lead : left aileron, right aileron
    • 9g plastic gear standard with 200mm lead : elevator
  • Required Battery: 3S 11.1V 1600mAh to 4S 14.8V 2200mAh LiPo with XT60 connector
  • Material: EPO Foam

Variants

FLW102P
FW 190 D-9 Dora (Khaki Camo)
