Urukay Genesis from Sab Avio

Details

Made for F3C competition! The brand new SAB URUKAY GENESIS is the evolution of the URUKAY COMPETITION with the new ingenious basic chassis of the SAB GOBLIN RAW 700.
In combination with the adjustable rotor head, the new 747mm F3C rotor blades and the direct linkage, maximum precision is achieved. All optimized for F3C competitions and sport flying.

The same battery rails are used as in the Kraken 700/580 - H1102-S.
H0175-xx-S motor belt wheels also fit in the URUKAY GENESIS.

Features:

  • The new SAB Urukay Genesis is not only intended for F3C pilots.sg747-sab-goblin-urukay-genesis-_4_-woh.jpg
  • This is a first-class model for all pilots who want lightweight elegance in full fairing.
  • Based on the well-known SAB quality standard and influenced by the experience of top pilots
  • the Urukay Genesis is not only an eye-catcher, but has also reached the pinnacle of technical development.

Pictures

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.


Wingspan: 1662mm (65.4 in)
Length: unknown

Weight: 2950 g (6.5 lbs)

  • Airframe weight: 2950gr (with blades, no battery, no electronics)
  • Main blade length: 690mm to 760mm
  • Tail blade length: 105 to 115 mm
  • Main rotor diameter: 1662 mm (with new F3c 747 mm blades included)
  • Tail rotor diameter: 284 mm (with 105 mm tail blades included)
  • Cyclic Servos: standard size 40mm
  • Tail Servo: standard size 40mm
  • Main Rotor ratio: 11.8 to 8.8 (21T included: 10.1:1)
  • Tail Rotor ratio: 5.0-4.8:1 (26T included: 4.9:1)
  • Typical motor: 4525 series
  • Typical speed controller: 12S, 160-200 A
  • Battery size: 12S 4500-5500 mAh
