JAS-39 Gripen from Freewing Model

Details

The JAS 39 Gripen’s unique delta wing and canard configuration endows it with excellent agility, most notably a tighter turning radius than the American F-16! Flown by more than a dozen NATO countries, the Gripen is a Mach 2 multi-role fighter whose 25 year service history continues onward with distinction.

Freewing has raised the bar again for RC foam electric delta winged jets with the JAS 39 Gripen. This jet is precisely modeled for scale fidelity and practical RC performance, and assembles in minutes including pre-installed electronics and LED lighting. Powered by our popular 80mm 9-blade Inrunner EDF and a 100A ESC, the Freewing Gripen is designed for power! At ~1/9 scale and 1613mm/63” in length, the Freewing Gripen is longer than its predecessor, the Freewing Typhoon/Eurofighter. Referencing the full size Gripen’s short take-off capabilities, the Freewing Gripen is optimized for short take-offs and surviving unkempt landing strips.

Recommended for intermediate to advanced skill level pilots, the Freewing Gripen offers the power, size and speed of a 90mm super scale jet, in a lighter, faster, and more economical 80mm EDF Series package. Full-functioning canards enable high agility, and full-coverage gear doors improve the airframe’s overall aerodynamics.

Features:

  • Full Function canard operation
  • 9-blade EDF with 3658-1920kV Inrunner brushless motor for incredible efficiency and performance surpassing 170kph/105mph top speed
  • Full-coverage landing gear doors for optimized aerodynamics
  • Durable metal landing gear for operation on grass and gravel runways
  • Preinstalled ball linkage and decals
  • 63” total length
  • 12” long removable magnetic nose cone for easy transportation
  • True-To-Life livery commemorating the 100th Anniversary of Allied and NATO service of the Czech Air Force

Description and pictures from MotionRC

Pictures

Manual

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.


Wingspan: 882mm (34.7 in)
Length: 1613mm (63.5 in)

Weight: 2350 g (5.2 lbs)
  • Wingspan: 882mm /35in
  • Length: 1613mm / 63in
  • Weight: 2350g / 83oz (w/o battery)
  • CG (Center of Gravity): Molded Into Fuselage (130mm aft of canard root)
  • Power System: 6S 3658-1920kV Inrunner Motor (included)
  • ESC: 100A with 5A UBEC (included)
  • EDF: 80mm 9-Blade EDF (included)
  • Required Battery: 6S 22.2V 4000-6000mAh LiPo with EC5 Connector
  • Material: EPO Foam

Other Variant(s)
