DG-800 S from CARF

Details

The DG-800 S from “Schauberger’s Model Manufacture” is known in Germany as the“UNDESTROYABLE”. Sure enough she is one of the fastest, most precise giant scale gliders ever made.

CARF-Models have taken over the production of this magnificent glider in a team effort with Schauberger. They have transitioned the extreme aerodynamical performance and incredible structural strength of the bespoke airplane into professional and reliable serial production.

No matter what your expectations are, the DG-800 S has something for everybody, as long as the main objective is to simply not settle for anything less than the Best. The performance spectrum spans from thermal flight in very marginal thermal weather, all the way to slope soaring in extreme conditions. The adjustable camber over the whole wing span changes the characteristics of the airplane dramatically. Due to the strength of the all carbon construction even extreme towing with most powerful tow planes and rocking turbine flights at continuous maximum speed are possible. Not only the structural strength, but also the aerodynamic design as such allows high inertia aerobatics in any altitude.

Features:


The less experienced glider pilot will appreciate the versatility of our DG-800 S as he can fly it at the slower end of the performance span, growing with increasing routine and experience into challenging the airframe at highest speeds, with loaded ballast, all with one aircraft which can’t get better than it is.

Now, what do you get for your money in terms of design, construction, prefabrication and included equipment, when you opt for one of these high performance glider?

  • A kevlar reinforced fuselage, seamless, with canopy frame and canopy readily installed and hinged, carbon reinforced retract formers, hinged gear doors.
  • All joints for wings, horizontal stab and rudder are readily built and aligned.
  • A pair of wings built in the latest all carbon technology. All flaps and ailerons are skin hinged and the bottom slots are covered with the full size equivalent of hinge seals. Control horns are installed, servo trays and linkages are prepared so that servos of various types literally snap in place. Speed brakes are installed and their covers are precisely aligned with the wing’s surface.
  • A massive carbon wing joiner as a floating spar, built and pressed in steel moulds, individually fit without any play into the wing sockets
  • A horizontal stab and rudder, ready to be attached, control horns installed, hinge slots sealed.
  • A high end retract, a CNC-machined canopy hinge with integrated tow release, and all hardware required to complete the airplane

Pictures

Manual

Radio icons

FrSky X20

FrSky XE

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X10

FrSky X12s

JPG (155x100)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the DG-800 S in particular but at least we know they do distribute CARF.

Wingspan: 6000mm (236.2 in)
Length: 2350mm (92.5 in)

Weight: 18000 g (39.7 lbs)

As a very impressive option, maybe a industry first, CARF provides a turbine conversion set, consisting of a precisely moulded turbine mount for 100N class turbines and a conformal fuel cell with a hopper tank for the die hard speed freak. Performance glider flying at its best, just the word “glider” might be a bit out of touch.

10x High Power digital Servos
