Velox Revolution from EXTREME FLIGHT

Details

The Velox Revolution is a full-scale aerobatic aircraft produced by Charlie Wolff at Velox Aviation. It was among the first piston-engine aerobatic designs to be produced from a majority of composite airframe parts. The Velox has been in production since the mid-1990’s, and as of 2017, Charlie had completed 10 copies, in both Revolution I (single-place cockpit) and II (dual cockpit) versions.

The Velox is an interesting design subject for an aerobatic model because it’s “right” in the full-scale design, (mid-low wing, low stab, low thrust line) and does not have to be molested much to optimize it as a model.

The 52”

Starting from this great base, the 52” version is a stellar performer. Sporting huge tail surfaces, the Velox slots into the 52” lineup as the hooligan airplane. Chris and I, talking about how to describe its mission, decided on “classic 3D flying” as the best descriptor. The Velox covers all the 3D bases with low coupling at high rudder throws, for super low and slow HAKE passes and tight spins, and easy in-your-face hover and torque-roll.

The Velox includes SFG’s and I fly with them on, as there’s no downside to them. They make the big rudder seem even bigger and damp out any unwanted roll motion, especially in a breeze. A fun note, the full-scale Velox actually has an option for SFG’s, so they’re a scale feature.

Construction and Assembly

The Velox builds in the same easy, confidence-inspiring sequence as our other 52” designs, with the self-centering horizontal stab system. All the hardware is the tested-and-true system from our other 52” aircraft, and it uses the same equipment, based around the awesome XPWR 3910 motor.

The Velox is available in two genuine Oracover schemes with a high-contrast bottom surface design for easy and quick orientation.

A personal note from designer, Ben Fisher.

The Velox has always been a special aircraft to me. 3DHobbyShop has produced several Velox aircraft over the years in various sizes, and they have always been a go-to airplane for crazy 3D flying. This Velox continues that tradition, but it’s so much better than aircraft of this size could ever be, back in the day. As much as the Extreme Flight construction system makes these aircraft a joy to assemble and own, it also makes the design process a joy. Light, strong, straight, stiff, durable and precise, these 52” aircraft are the pinnacle for small aerobats, and I’m very happy to add a Velox to the lineup.

An Extreme Flight Cyclone 57mm spinner is included!

Pictures

Radio icons

(Click on the icon you want to download)
Horus & T16 OpenTx
Horus FrOs
Standard
Silhouette
X9D/X9D+/X9E
Spektrum IX12
Futaba 18MZ
Jeti DS-24

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Velox Revolution in particular but at least we know they do distribute EXTREME FLIGHT.

Where to buy

France
Flash RC
check web site
Ship to: Europe
France
interModel
check web site
Ship to: France
Hungary
RC Hungary
check web site
Ship to: Hungary
Germany
Modellbau Berlinski
check web site
Ship to: International
Germany
Schweighofer GE
check web site
Ship to: Germany
Austria
Schweighofer AT
check web site
Ship to: International
Switzerland
Grischa Modellbau
check web site
Ship to: Switzerland
Belgium
Aerobertics
check web site
Ship to: Europe
Austria
DMT
check web site
Ship to: Europe

Wingspan: 1320mm (52 in)
Length: 1295mm (51 in)

Weight: 1810 g (4 lbs)
  • Wingspan: 52 inches (1320 mm)
  • Length: 51.5 inches with spinner (1295 mm)
  • Wing area: 565 square inches
  • Weight: 3.75-4 lbs. (1810 g)
  • Spinner: 57 mm
  • Servos : 4x Hitec 5087MH



Electric Power System

  • Xpwr T3910 electric motor
  • Airboss 80 amp electronic speed control
  • 14 x 7 or 15 x 7 electric prop
  • 4S 2500-3300 mAh batteries



Variants

384YR
Velox Revolution (Red Yellow)
